Alumina Ceramic Pumpsmerits
One of the core advantages of alumina ceramic pumps lies in their excellent wear resistance. Due to the high hardness of the material itself, even under the working conditions of continuous reciprocation of the plunger, high-speed liquid impact and long-term friction of particulate media, it is still able to maintain good surface finish and dimensional accuracy, and is not easy to produce scratches or abrasion. Compared with the traditional metal pump parts are more likely to wear gap increase, alumina ceramic pumps can maintain excellent sealing effect and stable conveying accuracy for a long time, effectively improve the overall service life of the equipment.
Description
Aluminum oxide ceramics泵merits
Alumina ceramic pumps are wear-resistant, corrosion-resistant, high-temperature-resistant, with high sealing precision, stable delivery, long service life, and clean and pollution-free. Especially suitable for chemical metering pumps, pharmaceutical infusion pumps, high-purity liquid transfer pumps, automated precision fluid equipment and other demanding conditions, is a high-quality program to replace the traditional metal pump core and plastic pump parts.
- High purity aluminum oxide material
- High hardness and wear resistance
- Acid and alkali resistant
- High temperature and thermal shock resistant
- Excellent electrical insulation properties
- Support non-standard customized processing
Aluminum oxide ceramics applications
Alumina ceramics are the most common advanced ceramic material and more traditional. As an excellent ceramic material, high purity alumina ceramics have been widely used in many industries. The material has excellent properties in terms of electrical insulation, high thermal conductivity, high chemical resistance, good wear resistance and low thermal expansion. Therefore, alumina ceramic products are ideal for many industries such as:
- Shafts and plungers in high wear environments
- Roller and ball bearings
- Wear-resistant lining
- semiconductor part
- Machine components
- High temperature electrical insulators
- High-voltage insulators
- Wires and conductors
- mechanical seal
Basic Properties of Alumina Ceramics
Alumina is an excellent high temperature ceramic material due to its high temperature stability. It is one of the most commonly used high grade ceramics. Zhihao Ceramics offers alumina ceramics with purity ranging from 95% to 99.5%.
- Excellent electrical insulation (1×1014to 1×1015 (Ω cm);
- Medium to ultra-high mechanical strength (300 to 630 MPa);
- Very high compressive strength (2000 to 4000 MPa);
- High stiffness (15 to 19 GPA);
- Medium thermal conductivity (20 to 30 W / MK);
- Low density (3.75 to 3.95 g/cm)3);
- Operating temperature 1650°C without mechanical load;
- Biologically inert, food compatible.
Suppliers of Aluminum oxide ceramics
To Good Ceramics is a professional ceramic supplier, we have many years of experience in producing high quality precision ceramic parts. We utilize our experienced team and in-depth knowledge of ceramic materials to create the best precision ceramic products for our customers at competitive prices.
